Round Acoustic Hanging Baffles

Incorporating TECHLITE®Round Hanging Baffles can reduce noise, excessive reverberance, increase speech intelligibility, reduce stress and stress-related symptoms, help maximize concentration and increase overall comfort.

Part Number: TA-017
Get A Quote
View full details

In Any Given Room More Often Than Not, Treating The Ceiling Can Often Lead To The Best, Most Viable Acoustical Solution For Controlling Noise, Which Is Commonly Defined As Unwanted Sound In The World Of Acoustics.

The option to suspend sound-absorptive treatment as baffles from the structural and/or finished ceiling offers design flexibility as well as provides a multitude of acoustic solutions related to the architectural design. Disparate from, say, treatment direct-attached, glued, screwed, etc., to the finished ceiling or wall, suspending sound-absorptive baffles from the structural ceiling provides the room in question several additional acoustical benefits. One remarkable benefit to gain from vertical baffle installation is the diffraction effect, where the sound wave is dissolved and evenly dispersed throughout the space as a result of the wave moving across the edges and sides of the baffle, thus the noise becomes subjectively less-intrusive to the listener. In addition, because the baffle is suspended vertically, a larger surface area of the baffle is left exposed to the sound field. As a result you have an end-product that is acoustically-superior to the traditional direct-attached ceiling and/or wall panel.

Incorporating TECHLITE® Round Hanging Baffles can reduce noise, excessive reverberance, increase speech intelligibility, reduce stress and stress-related symptoms, help maximize concentration and increase overall comfort. Therefore, TECHLITE® Round Hanging Baffles should be used in noisy, excessively-reverberant, acoustically-uncomfortable environments where the intended aesthetic does not accommodate a hard lid or acoustical tile ceiling, or where the ceiling on its own is not providing sufficient sound absorption to the space. By supplementing the existing finished ceiling with TECHLITE® Round Hanging Ceiling Baffles, the acoustical signature of the environment can be dramatically improved with a reduction in reverberation (echoes) as well as the overall perceived sound level.

The baffles should be suspended as close to the sound source as reasonable, and should be evenly dispersed throughout the sound field as opposed to larger clusters to enhance the diffraction effect and contribute to a more diffuse, balanced sound field. Available in both standard and custom sizes and colors, TECHLITE® Round Hanging Baffles can be hung from aircraft cable and corkscrew hangers in minutes.


The information contained in this data sheet derives from accredited laboratory tests, but without warranty. The physical properties are typical values and intended for reference only. They are not specifications. Recommended uses are based on testing, but it is always recommended the customer evaluate the product suitability under their actual process conditions.

*The information contained in this data sheet derives from accredited laboratory tests, but without warranty. The physical properties are typical values and intended for reference only. They are not specifications. Recommended uses are based on testing, but it is always recommended the customer evaluate the product suitability under their actual process conditions.

Additional Information

Benefits and Highlights

  • Open-cell, fiber-free melamine foam core
  • Lightweight, easy, flexible installation
  • Architecturally decorative
  • Tested in accordance with ASTM C423-17 for Sound Absorption
  • Class A fire-rated per ASTM E 84
  • Highly Sound-Absorptive (Apparent NRC 0.85 @ 6″ diameter, 24″ long)
  • High Light Reflectance
  • Increased speech intelligibility and overall comfort


Uses and Applications

  • Fitness facilities
  • Restaurant / Bars
  • Auditoriums
  • Lobbies
  • Office Buildings
  • Indoor Aquatic / Swimming Pools
  • Gymnasiums
  • Indoor Gun Range


Specifications

  • Size: 6" x 24", 4" x 24", 4" x 48", 6" x 12", 6" x 18", 6" x 36", Custom
  • Color: Natural White Foam, Light Grey Foam, Custom Coated
  • Coated: Blue Jay, Charcoal, Desert, Garnet, Hushed Grey, Latte, Mantis, Moss Green, Navy, Pitch Black, Poppy Blue, Red Jam, Sea Foam, Slate, Urban Bronze, White Noise, Not Coated, Sherwin-Williams (1,500+)
  • Thickness: 4", 6", Custom
  • Material: TECHLITE® Flexible Open-Cell Melamine Foam
  • Minimum Service Temp: -40°F
  • Maximum Service Temp: 350°F
  • Density: Light Grey 0.56 0.09 lb/ft3, Natural 0.47 0.13 lb/ft3
  • Fire Rating (Light Grey): ASTM E 84 Class A | Flame Spread Index = 10 / Smoke Developed Index = 55
  • Fire Rating (Natural): ASTM E 84 Class A | Flame Spread Index = 5 / Smoke Developed Index = 20, CAN/ULC S102 | Flame Spread Index = 0 / Smoke Developed Index = 30
